A quick way to duplicate all of the custom chart formatting

Excel 365 2016 2013 2010 2007
Creation of a large number of visually consistent charts to represent different data is a time consuming and error prone task, unless you know how to copy formatting between charts.

You have several options:

  • Copy the formatting: Create a standard chart with the default formatting.

    Then select your original chart and choose Edit -> Copy. Click your new chart and choose Edit -> Paste Special. In the Paste Special dialog box, select Formats.

    Paste Special in Excel 2003
  • Copy the chart: Hold down Ctrl while you click the original chart and drag.

    This creates an exact copy of your chart. Then use the Chart -> Source Data dialog box to specify the data for the new chart.

    Source Data in Excel 2003
  • Create a user-defined chart type: Select your chart; then, choose Chart -> Chart Type. Click the Custom Types tab and select the User-Defined option.

    Click the Add button and then provide a name and description. When you create your next chart, use this custom chart type.

    Custom Type in Excel 2003
